| Features |
|---|
★ 32 inch , 1920x1080 (FHD) Resolution
★ VA Wide Viewing Angle Technology (178 °/178°)
★ Intel® Skylake/ Kaby Lake CPU
★ DDR4 8G RAM (Max. 32G)
★ Serial ATAIIIx1, mSATA/mPCIe x1
★ True Flat Projected Capacitive Touch Screen, 7H Hardness Tempered Cover Glass
★ 10 points Multi-touch, Supports Active Stylus
★ Metal Cabinet with Diverse Combine Options
★ Made in Taiwan, 3 Years Warranty, Designed for Harsh Environments
★ Max High Brightness 2500nits for Sunlight Readable
| System Specifications | |
|---|---|
| CPU | Intel® Skylake, Kaby Lake Celeron/Core I series CPU |
| Memory | DDR4 SO-DIMM x2, Max. 32G |
| Storage | SATA x1, mSATA/mPCIe x1 |
| GPU Chip | Intel® HD Graphics |
| Sound Chip | Realtek ALC662 Audio CODEC |
| Network | Intel Gigabit LAN, 2 * RJ45 ports |
| Display Specification | |
|---|---|
| Panel Process | VA Mode, Normally Black |
| Display Size |
32 inch |
| Visible Area | 698.4x392.9 mm |
| Resolution | 1920x1080 (FHD) |
| Color Depth | 16.7M Colors |
| Brightness (nits) | 500 / (Optional) 1000 / (Optional) 1500 nits |
| Contrast Ratio | 4000:1 |
| Display Ratio | 16:9 |
| Pixel Pitch | 0.3637x0.3637 mm |
| Response Time | 10 msec. |
| Viewing Angle | 178°/178° |
| Backlight | LED (white LED) |
| Backlight Lifetime | >50000 hours |
| Operating Temp. | 0°~50°C |
| Storage Temp. | -20°~60°C |
| Touch Specification | |
|---|---|
| Touch Technology | Projected Capacitive |
| Allowed Touch Points | 10 points |
| Thickness of Cover Lens | 2.9±0.2mm |
| Hardness of Cover Lens | 7H |
| Accuracy | 99.00% |
| Transparency | ≧87% |
| IK Ratings | IK07 |
| Optional Accessories | |
|---|---|
Wall Mount Bracket |
KIOSK |
Passive Stylus |
Cart |
| Product Specifications |
|---|
| NTWP320 V500 English Version |
| NTWP320 V500 Traditional Chinese Version |
| NTWP320 V500 Japanese Version |
