| Features |
|---|
★ Intel® 13th Generation Core i Series CPU
★ DDR4 8G RAM, Max to 32G
★ GbE LAN Port x2
★ 128G SSD, Max to 1T
★ HDMI Output x1, DP output x1
★ Realtek Audio HAD Codec,
★ RS485 Port x1, RS232 Port x6
★ USB 3.0 x6
★ Metal Cabinet
★ Made in Taiwan, 3 Years Warranty
| System Specifications | |
|---|---|
| CPU | Intel® Core i U Series Processor |
| Memory | DDR4 SO-DIMM, Max. Capacity 32G |
| Network | 2 * Intel® GbE LAN Chip (10/100/1000 Mbps, RJ45) |
| Storage |
SATA3.0 7P Connector (With 1 * SATA Power Wafer)x1 M.2 Key-M Slot (PCIe x4/ SATA, Default PCIE 4x, Support PCIe x4 NVMe, 2280) x1 |
| Video Output |
Intel® UHD Graphics (for i3 CPU) Intel® Iris Xe Graphics (for i3/i5 CPU) HDMI output x1, Max. Resolution 2048x1080 @60Hz DP output x1, Max. Resolution 4096x2304 @60Hz |
| Sound Chip | Realtek Audio HAD Codec |
| Rear I/O |
HDMI x1,DP x1 RJ45 LAN Ports x2 USB 3.0 x6 RS485 x1, RS232 x6 Line-Out + MIC 2in1 3.5mm Jack x1
|
| Operating Temp. | 0~60℃ |
| Storage Temp. | -20~75℃ |
| Power Input | 12VDC-in |
| Optional Accessories | |
|---|---|
Wall Mount Bracket |
 |
