| Features |
|---|
★ Intel® Alder Lake N97 CPU
★ DDR4 8G RAM, Max to 16G
★ GbE LAN Port x2
★ 128G SSD, Max to 1T
★ HDMI Output x1, DP output x1
★ Realtek Audio HAD Codec,
★ RS485 Port x1, RS232 Port x6
★ USB 3.0 x4, USB 2.0 x2
★ Metal Cabinet
★ Made in Taiwan, 3 Years Warranty
| System Specifications | |
|---|---|
| CPU | Intel® Alder Lake-N97 Processor |
| Memory | DDR4 SO-DIMM 8G, Max to 16G |
| Network |
Intel i210-AT GbE Ethernet Controller x1 Intel i226-V GbE Ethernet Controller x1 |
| Storage |
M.2 M-Key 2280, PCIE X1/SATA, Support PCIE X1 NVMe/SATA SSD, Auto Detect SATA3.0 6Gbps
|
| Video Output |
Intel® UHD Graphics HDMI output x1, Max. Resolution 4096x2160 @30Hz DP output x1, Max. Resolution 4096x2160 @60Hz
|
| Sound Chip | Realtek Audio HAD Codec |
| Rear I/O |
HDMI x1,DP x1 RJ45 LAN Ports x2 USB 3.0 x4, USB 2.0 x2 RS485 x1, RS232 x6 Line-Out + MIC 2in1 3.5mm Jack x1
|
| Operating Temp. | 0~60℃ |
| Storage Temp. | -20~75℃ |
| Power Input | 12VDC-in |
| Optional Accessories | |
|---|---|
Wall Mount Bracket |
 |
| Product Specifications |
|---|
| NTWB512 V100E English Version |
| NTWB512 V100E Traditional Chinese Version |
| NTWB512 V100E Japanese Version |
