| Features |
|---|
★ 27 inch Panel, 1920x1080 (FHD) Resolution
★ VA Wide Viewing Angle Technology (178°/178°)
★ Rock Chip ARM Cortex A72+A53 RK3399 Quad-Core CPU
★ On Board DDR4 4G Memory
★ On Board 32 Flash ROM
★ Micro SD Card Slot x1
★ Android 11
★ Narrow Bezel, True Flat Projected Capacitive Touch Screen
★ 7H Hardness Tempered Cover Glass
★ 10 points Multi-touch, Supports NEXTECH Dedicated Stylus
★ Metal Cabinet with Diverse Combine Options
★ Made in Taiwan, 3 Years Warranty
★ Optional High Brightness 1000nits, for Outdoor Environment
★ Optional AG Coating/Anti-UV/Antibacterial/Privacy Filter Surface Treatment
| System Specifications | |
|---|---|
| CPU | Dual Core ARM Cortex-A72 +Cortex-A53 up to 2.0GHz |
| Memory | DDR4 4G |
| Storage | 32G Flash ROM |
| Sound Chip | Everest ES8336 Codec |
| Physical Network | Realtek GbE LAN Chip (RJ45, 10/100/1000 Mbps) |
| Wireless Network | Wi Fi 2.4/5GHz and Bluetooth 4.2 (support BLE) |
| OS | Android 11 |
| Display Specification | |
|---|---|
| Panel Process | VA Type, Normally Black |
| Display Size |
27 inch |
| Visible Area | 597.6x336.2 mm |
| Resolution | 1920x1080 (FHD) |
| Color Depth | 16.7M Colors |
| Brightness (nits) | 250 / (Optional) 1000 nits |
| Contrast Ratio | 3000:1 |
| Display Ratio | 16:9 |
| Pixel Pitch | 264x264 um |
| Response Time | 5 msec. |
| Viewing Angle | 178°/178° |
| Backlight | LED (white LED) |
| Backlight Lifetime | >30000 hours |
| Operating Temp. | 0°~50°C |
| Storage Temp. | -20°~60°C |
| Touch Specification | |
|---|---|
| Touch Technology | Projected Capacitive |
| Allowed Touch Points | 10 points |
| Thickness of Cover Lens | 2.9±0.2mm |
| Hardness of Cover Lens | 7H |
| Accuracy | 99.00% |
| Transparency | ≧87% |
| IK Ratings | IK07 |
| Optional Accessories | |
|---|---|
Open Frame Brackets |
Wall Mount Kits |
IP65 Waterproof Protection Front Frame |
Wall Mount Bracket |
Desktop Stand B type |
Desktop Stand Z type |
Passive Stylus |
 |
